Material

Fly sheet:
150D HYPERTEX Polyester PU, 3.000 mm

Ground sheet:
 Sewn in PE floor

Poles:
TPU Air beam 10 cm
Alu 9,5 mm

Colors

Light grey-dark grey-blue

Features

Self supporting Air tube awning

• Steel roof bar 19 mm
• High grade TPU beams covered with 2 layers
• 2 speed valves outside
• 3 roof supporting TPU air tubes
• Double action pump
• Fully sewn- in ground sheet with external Oxford mud skirt
• Pre- bended structure with curved roof offer great space
• Porch
• Divisable veranda front fully to open
• Veranda ground sheet with fold down function by zipper
• Panoramic crystal clear window front with cover
• Mesh window
• Mesh side entry with zipper fabric
tape seamsealed
• Top ventilatioon
• Zipped cable point entry
• Rear porch with 2 entries
• Full zipped 50/50 roll away rear porch
with Easy Stow Away pocket
• Double kador strip 5,8/7,2 mm
• Pole and 4 clamps
• 4 touch fastener roof bar attachment tabs
• Rear porch height 180-220 cm

• Zipped packsac
• Optional inner tent 141467
• Seam sealed

Specification

Self- supporting air inflatable awning with pre-bended structure and curved roof offer great comfort. High quality 150D Hypertex fabric. The beams allows all in one pitching in 5 minutes. The sewn in groundsheet with external mud skirt keep out dirt and unwanted insects and terrestrials. Divisible new designed veranda front enable to roll up the complete front creating more space. The ground sheet wall can be fold down by zipper to a flat entry. Expansive porch extend the living area provide shadow and weather protection. Crystal clear panoramic windows with privacy covers. Side entry with mesh door and mesh window increase ventilation. All- weather ventilation underneath the porch. Connection panel with two doors allows convenient access. Divisible zipped roll- away door connection panel with Easy Stow Away pocket. Extra strong zips. External zipped cable entry point. Three air- roof bars with Velcro attachments for more stability. Rear porch with attached kador strips 5,8/7,2mm. Option bedroom offer sleeping space. Designed to fit 180-220cm vehicle.

Porch fixations
Kador strips 5,8/7,2mm. Most common connection to vehicle Pole and three clamp kit sleeve. For vehicle without kador rail Touch fastener roof bar attachments. Wrap around the vehicle roof bars. Quick and easy Pole and guy line sleeve. Most simple connection.

Art.-No.

14157

RRP

€ 689,95
